Off camera flash for close-ups
Page 1 of 1 • Share •
Off camera flash for close-ups
There are many ways to get your flash gun/strobe off of your camera.
You can use a cable or a optical slave cell these are cheap or a radio wireless trigger expensive.
In the shot below I have used a old Nikon strobe a SB-26 that has an inbuilt optical slave cell.
This slave cell fires the strobe when it sees a flash from another flashgun/strobe, so it can be triggered by the built-in flash of your DSLR. This is how the picture was made.
I had the DSLR flash set to manual and 1/125th power, and the Sb-26 set to manual and 1/16th power. I then held the strobe in my left hand and the camera in my right. you could use a tripod or light stand for the flash.
the camera was on manual 1/200sec f45 300mm lens at 2foot 0.5meters from subject.
These are not the best shots ever but taken just to show how this works for this brief article.
Shot 1 lit with the camera in-built flash.
OK but very flat.
Shot 2 strobe off camera.
Better I think and more DoF, so sharper front to back.
Like I said not the best shots but I made these while sitting a my desk at work reading my emails, and start to finish 5 mins.
You can use a cable or a optical slave cell these are cheap or a radio wireless trigger expensive.
In the shot below I have used a old Nikon strobe a SB-26 that has an inbuilt optical slave cell.
This slave cell fires the strobe when it sees a flash from another flashgun/strobe, so it can be triggered by the built-in flash of your DSLR. This is how the picture was made.
I had the DSLR flash set to manual and 1/125th power, and the Sb-26 set to manual and 1/16th power. I then held the strobe in my left hand and the camera in my right. you could use a tripod or light stand for the flash.
the camera was on manual 1/200sec f45 300mm lens at 2foot 0.5meters from subject.
These are not the best shots ever but taken just to show how this works for this brief article.
Shot 1 lit with the camera in-built flash.
![]() |
| From 2009 02 27 |
OK but very flat.
Shot 2 strobe off camera.
![]() |
| From 2009 02 27 |
Better I think and more DoF, so sharper front to back.
Like I said not the best shots but I made these while sitting a my desk at work reading my emails, and start to finish 5 mins.

Simon.fairclough- Moderator
- Number of posts: 660
Location: London UK

Great way of doing flash photography...
Hi Simon
I think you started a really interesting discussion...something that fascinates me also from my G7 days. The smaller 28 / 34 series of Metz also has this slave function, so have a number of Canon flas units.
I like the result of the second picture, it looks great.
Sunday I have a date with my daughter to do portrait work. I am planning to use off camera flash techniques plus I will try reflectors for the first time....
Have a nice weekend
Siegfried
I think you started a really interesting discussion...something that fascinates me also from my G7 days. The smaller 28 / 34 series of Metz also has this slave function, so have a number of Canon flas units.
I like the result of the second picture, it looks great.
Sunday I have a date with my daughter to do portrait work. I am planning to use off camera flash techniques plus I will try reflectors for the first time....
Have a nice weekend
Siegfried
Siegfried- Number of posts: 858
Age: 48
Location: Bern, Switzerland
Re: Off camera flash for close-ups
You can do this with the G7 and that can sync at any shutter speed.
I will do a off camera flash for the G7 soon.
I will do a off camera flash for the G7 soon.

Simon.fairclough- Moderator
- Number of posts: 660
Location: London UK

Re: Off camera flash for close-ups
G7 off camera flash article in show us your pictures.
See self portrait.
See self portrait.

Simon.fairclough- Moderator
- Number of posts: 660
Location: London UK

Re: Off camera flash for close-ups
Hi Simon
Did I miss something...I do not see the article....or is it comming.
Summer is here and macro pics will be key soon...flower pics
Best
Siegfried
Did I miss something...I do not see the article....or is it comming.
Summer is here and macro pics will be key soon...flower pics
Best
Siegfried
Siegfried- Number of posts: 858
Age: 48
Location: Bern, Switzerland
Re: Off camera flash for close-ups
Yes Sigi, the article is in Portrait Photography/self portrait.
http://mycanong7.forumotion.com/portrait-photography-f17/self-portrait-t599-15.htm#3144
I can see the flowers from my office window but were is the time to do this?
http://mycanong7.forumotion.com/portrait-photography-f17/self-portrait-t599-15.htm#3144
I can see the flowers from my office window but were is the time to do this?
